XUY474NB4H03M12


Telemecanique Sensors Roller Sensor For

Conveyor474 Mm N4- Es93 Ip50 Hex Fix Cable 30cm- Connectm12

Telemecanique Sensors

Your cart total:

.

Checkout

0

XUY474NB4H03M12








































Brand:Telemecanique Sensors
Product Type:Colour Sensor
Family:OsiSense
Series:XUY
Manf. Part No.:XUY474NB4H03M12
Description:Telemecanique Sensors Roller Sensor for Conveyor 474 MM N4- ES93 IP50 Hex Fix Cable 30cm- connect M12
Rated control supply voltage Us at DC:24V
Voltage type:DC
Max. output current:100mA
No load current:35mA
Switching frequency:500Hz
Type of electric connection:Connector M12
Analogue output 0 V ... 10 V:No
Analogue output 0 mA ... 20 mA:No
Analogue output 4 mA ... 20 mA:No
Analogue output -10 V ... +10 V:No
With other analog output:No
Type of switching output:NPN/NPN
Type of switch function:Programmable/configurable
Setting procedure:Other
Measuring process for colour detection:Active tristimulus method
Type of light:Infrared light
Material housing:Aluminium
Material of optical surface:Other
Material of cable sheath:Other
Material fibre optics core:Plastic
Construction type housing:Cylinder plain
Length of sensor:474mm
Diameter sensor:12mm
Nominal operating distance:100mm
Operation agent-safety class:Other
With blanking function:Yes
With fibre optics connection:No
With exchange lens:No
With time function:No
Ambient temperature:-10°C - 55°C
Degree of protection (IP):IP50
GTIN:3389119623018
