XS8C2A4DAM12


Telemecanique Sensors Inductive Sensor

Xs840x40x70, Pbt, Sn40 Mm, 12..48vdc, M12

Your cart total:

0

XS8C2A4DAM12









































Brand:Telemecanique
Product Type:Inductive Proximity Switch
Manf. Part No.:XS8C2A4DAM12
Width Sensor:70mm
Height of Sensor:40mm
Length of Sensor:40mm
Mounting Style:Not flat
Switching Distance:40mm
Suitable for Safety Functions:No
Switch Function:Normally Open
Type of Switching Output:Two-wire
Electrical Connection:Connector M12
No. of Semiconductor Outputs with Signalling Function:1
No. of Contact Energized Outputs with Signalling Function:0
No. of Protected Semiconductor Outputs:1
No. of Protected Contact Energized Outputs:0
Actuation Type:Metallic Target
Type of Interface:None
Type of Interface for Safety Communication:None
Housing Construction:Standard construction
Housing Coating:Other
Cascadable:No
Category According to EN 954-1:1
SIL According to IEC 61508:None
Performance Level acc. to EN ISO 13849-1:None
Max. Output Current at Protected Output:100mA
Supply Voltage:12V - 48V
Rated Control Voltage Us at AC 50HZ:
Rated Control Voltage Us at AC 60HZ:
Rated Control Voltage Us at DC:12V - 48V
Voltage Type:DC
Switching Frequency:200Hz
Monitoring Function for ownstream Switching Devices:No
Housing Material:Plastic
Compression Resistant:No
Explosion Safety Category for Gas:None
Explosion Safety Category for Dust:None
Interference Resistance to Magnetic Fields:Immune against magnetic DC-field
GTIN:3389119058032

No extended details available.
