VT12T2P430


SICK PROXIMITY SENSOR

Sick

Your cart total:

.

Checkout

0

6026216



































Manufacturer:SICK
Model:VT12T-2P430
Height (mm):65.5
Weight (kg):0.018
Series:Photoelectric Sensors
Sensor/Detection Principles:Photoelectric proximity sensor, energetic
Housing design:Cylindrical, straight
Thread diameter:M12 x 1
Sensing range max:0 mm … 340 mm
Sensing range:2 mm … 300 mm
Type of light:Infrared light
Light source:LED
Light spot (distance):28 mm (300 mm)
Wave length:880 nm
Sensitivity Adjustment:Manual, via teach-in button, electronic, via control input C (0 V)
Angle of dispersion:5.3°
Supply voltage:10 V DC … 30 V DC
Ripple:< 10 %
Power consumption:20 mA
Output type:PNP
Switching mode:Light/dark-switching
Switching mode selector:Selectable via control input C
Output current Imax:100 mA
Response time:< 1.25 ms
Switching frequency:400 Hz
Connection type:Connector M12, 4-pin
Circuit protection:A, B, C, D
Protection class:III
Housing material:Nickel-plated brass/PA
Optics material:PMMA
Enclosure rating:IP 67
Ambient operating temperature:-25 °C … 70 °C
Ambient storage temperature:-25 °C … 70 °C
