| Supply voltage Vs: | 12 V ... 30 V. Limit values, reverse-polarity protected. Short circuit-protected mains operation: max. 5 A at 30 V DC. When using IO-Link output Vs > 18 V. When using analog voltage output Vs > 13 V. |
| Ripple: | ≤ 5 Vpp. May not fall short of or exceed VS tolerances. |
| Power consumption: | ≤ 2 W. At ambient temperature ≥ 0 °C. |
| Initialization time: | 1,100 ms |
| Warm-up time: | ≤ 1 min |
| Housing material: | Metal (zinc diecast) |
| Window material: | Plastic (PMMA) |
| Connection type: | Cable with male connector, M12, 5-pin, 300 mm |
| Indication: | 4 x LED, Full color LCD display |
| Weight: | 280 g |
| Dimensions (W x H x D): | 33 mm x 65 mm x 57.04 mm |
| Enclosure rating: | IP65, IP67 |
| Protection class: | III |
| MTTFD: | 101 years |
| Measurement range min ... max:: | 50 mm ... 80,000 mm, 90% remission factor. At good ambient conditions, at measurement cycle time ≤ 3,000 ms., 50 mm ... 40,000 mm, 90% remission factor, 50 mm ... 14,000 mm, 6% remission factor. At the maximum permissible ambient temperature, the maximum measuring range may be reduced by up to 40%. |
| Target: | Natural objects |
| Resolution: | 0.1 mm |
| Repeatability: | ≥ 0.2 mm, Equivalent to 1 σ. |
| Measurement accuracy: | ± 2 mm. 6% ... 90% remission factor. Typical temperature drift: 0.05 mm/K. |
| Response time: | 33 ms ... 68 ms. Dependent on remission and measuring cycle time. |
| Output time: | 33 ms, 50 ms, 100 ms, 200 ms ... 3000 ms. Continuously changing data output. |
| Light source: | Laser, red. Wavelength: 655 nm, max. average power: < 1 mW, pulse length: > 400 ps. |
| Laser class: | 2 (IEC 60825-1:2014, EN 60825-1:2014+A11:2021) |
| Typ. light spot size (distance): | 5.5 mm x 7.5 mm (at 1 m), 6.5 mm x 7 mm (at 5 m), 7.5 mm x 6.5 mm (at 10 m), 12.5 mm x 8 mm (at 20 m), 21.5 mm x 11 mm (At 40 m) |
| Average laser service life (at 25 °C): | 100,000 h |
