1025362






































Manufacturer:SICK
Model:CDM420-0001
Height (mm):167
Width (mm):192
Depth (mm):70
Weight (kg):0.8
Series:Connectivity
Brief description:Modular connection module for one sensor
Supported products:CLV42x, CLV43x, CLV44x, CLV45x, CLV62x, CLV63x, CLV64x, CLV65x, ICR84x-2, ICR85x-2, LECTOR®62x, RFH620
Supports cloning module (CMC):Yes
Supports display module (CMD):Yes
Supports power supply module (CMP):Yes
Supports fieldbus gateway (CMF):Yes (PROFIBUS DP, Ethernet, DeviceNet)
Serial (RS-232, RS-422/485):Yes
Remark (Serial (Rs-232, RS-422/485)):Depending on sensor connected
Ethernet:Yes
Remark (Ethernet):Depending on Sensor connected; corresponding CMF fieldbus gateway additionally necessary
CAN bus:Yes
Remark (CAN bus):Depending on sensor connected
PROFIBUS DP:Yes
Remark (PROFIBUS DP):Corresponding CMF fieldbus gateway additionally necessary
DeviceNet:Yes
Remark (DeviceNet):Corresponding CMF fieldbus gateway additionally necessary
Switching inputs:Depending on sensor connected
Switching outputs:Depending on sensor connected
Optical indicators:5 LED
Power consumption:Power consumption of the sensor + 1 W
Housing:Polycarbonate
Enclosure rating:IP 65 (DIN 40 050)
Protection class:III (VDE 0106)
Housing colour:Blue (RAL 5012)
Scanner connection:15-pin D-Sub HD socket
Service plug:9-pin D-Sub socket (internal)
Ambient operating temperature:-35 °C ... 40 °C
Storage temperature:-35 °C ... 70 °C
Permissible relative humidity:± 90 %, non-condensing

No extended details available.
