7900183



































Manufacturer:SICK
Model:IH06-04NPS-VT1
Length (mm):50
Series:Inductive Proximity Sensors
Housing:Cylindrical
Diameter:6.5 mm
Sensing range Sn:4 mm
Assured sensing range Sa:3.24 mm
Installation type:Non-flush
Switching frequency:1,800 Hz
Output type:PNP
Output function:NO
Electrical wiring:DC 3-wire
Enclosure rating:IP 67
Connection type:Connector M8, 3-pin
Housing:Standard
Supply voltage:10 V DC … 30 V DC
Ripple:< 10 %
Voltage drop:< 1.8 V
Power consumption:< 10 mA
Time delay before availability:< 50 ms
Hysteresis:1 % … 20 %
Repeatability:< 5 %
Temperature drift (% of Sr):± 10 %
EMC:According to EN 60947-5-2
Output current Ia:< 200 mA
Short-circuit protection:Yes
Reverse polarity protection:Yes
Power-up pulse protection:Yes
Shock/vibration:30 g, 11 ms/10 Hz … 55 Hz, 1 mm
Ambient operating temperature:-25 °C … 70 °C
Housing material:Stainless steel (V2A, 304)
Housing cap material:Plastic, PBT
