750320


LUTZE MICROCOMPACT SIGNAL CONVERTER

SELECTABLE INPUT AND OUTPUT RANGE VIA DI P SWITCH OR DEFINITIVE PARAMETRS BY LOC A L CUSTOM PROGRAMING

Lutze

Your cart total:

.

Checkout

0

750320















Measurement Input:+30/-30 V, +50/-50 mA, DC +5 A/-5 A
Output Signal:0 – 10 V, -10 – +10 V, 0 – 20 mA, 4 – 20 mA
Nominal Voltage:DC 24 V
Operation Voltage Range:16.8–30 V
Rated Current:18 mA
Status Indication:LED green, red (error)
Temperature Error:<100 ppm FSR
Protection Class:IP20
Termination:screw terminal: 0.14–1.5 mm2
Height (mm):90
Width (mm):6.2
Depth (mm):115.5
Weight (kg):0.05

No extended details available.
