6036919


SICK ULTRASONIC SENSOR UM30-214113

Sick

Your cart total:

.

Checkout

0

6036919



























Manufacturer:SICK
Model:UM30-214113
Series:Ultrasonic Sensors
Resolution:0.18 mm
Working range, limiting range:350 mm … 3,400 mm, 5,000 mm
Repeatability:± 0.15 %
Accuracy:± 1 %
Response time:180 ms
Output rate:43 ms
Ultrasonic frequency (typical):120 kHz
Detection area (typical):See diagrams
Temperature compensation:Yes
Multifunctional input:1 x MF
Analogue output:1 x 0 V … 10 V (> 100 kO), 1 x 4 mA … 20 mA (< 500 O)
Resolution analogue output:12 bit
Sending axis:Straight
Supply voltage:DC 9 V … 30 V
Power consumption:< 2.4 W
Initialisation time:< 300 ms
Housing material:Nickel-plated brass, PBT, TPU
Connection type:Connector m12, 5-pin
Indication:LED display, 2 x LED
Enclosure rating:IP 67
Protection class:III
Ambient temperature:Operation: -25 … 70 °C, Storage: -40 … 85 °C
