6013335




































Manufacturer:SICK
Model:VTE18-4P4740
Height (mm):78
Weight (kg):0.1
Series:Photoelectric Sensors
Sensor/Detection Principles:Photoelectric proximity sensor, energetic
Housing design:Cylindrical, straight
Thread diameter:M18 x 1
Optical axis:Axial
Sensing range max:5 mm … 400 mm
Sensing range:5 mm … 350 mm
Type of light:Infrared light
Light source:LED
Light spot (distance):20 mm (400 mm)
Sensitivity Adjustment:Potentiometer, 270 °
Angle of dispersion:2.8°
Supply voltage:10 V DC … 30 V DC
Ripple:< 10 %
Power consumption:< 30 mA
Output type:PNP
Switching mode:Light/dark-switching
Output characteristic:Open collector
Switching mode selector:Selectable via L/D control wire
Output current Imax:100 mA
Response time:< 2 ms
Switching frequency:250 Hz
Connection type:Connector M12, 4-pin
Circuit protection:A, B, C, D
Protection class:III
Housing material:PBT/PC
Optics material:PMMA
Enclosure rating:IP 67
Ambient operating temperature:-25 °C … 70 °C
UL File Number:NMFT2.E175606
