09370100301

























RoHS Conformity:Yes
Size:10 B
Locking Type:2 levers on the hood
Material, Locking Lever:Stainless steel
Locking Lever:double locking lever
Type of Hood - Housing:Housings, bulkhead mounting
Series:Han M
Corrosion Resistance:ASTM B117-09 (500 h)
Surface, Hood - Housing:powder-coated
Material, Seal:FPM
Colour, Hood - Housing:RAL 9005 (black)
Material, Hood - Housing:aluminium die-cast
Hood:Yes
Style:Low construction
Flammability Locking Lever Acc. to UL 94:V 0
Protection Class Acc. to UL 50:NEMA Typ 4/4X/12
Approval GL:Yes
Degree of Protection Acc. to DIN EN 60 529:IP65
Limiting Temperature, Min.:-40 C
Limiting Temperature, Max.:125 C
Make:Harting
Product Range :Han 10M Base Panel 2 Levers
Net Weight:139.75 g
