09370035405




























RoHS Conformity:Please contact our customer service
Size:3 A
Special Style:with lanyard
Locking Type:1 lever on the housing
Material, Locking Lever:Stainless steel
Locking Lever:double locking lever
Type of Hood - Housing:Protection covers for hoods cable to cable
Series:Han M
Corrosion Resistance:ASTM B117-09 (500 h)
Surface, Hood - Housing:powder-coated
Material, Seal:FPM
Colour, Hood - Housing:RAL 9005 (black)
Material, Hood - Housing:zinc die-cast
Hoods and Housings:Hoods/Housings for higher environmental requirements
Flammability Locking Lever Acc. to UL 94:V 0
Protection Class Acc. to UL 50:NEMA Typ 4/4X/12
Approval GL:Yes
Degree of Protection Acc. to DIN EN 60 529:IP65 / IP67
Limiting Temperature, Min.:-40 C
Limiting Temperature, Max.:125 C
Make :Harting
Product Range :Han M Protect Cover Die Cast for Base
Height (mm):27
Width (mm):33.5
Depth (mm):25.3
Net Weight:23.6 g

No extended details available.
